MED-01 Medical Packaging Tester

MED-01 Medical Packaging Tester is professionally applicable to the determination of force properties of various medical packaging materials, with high precision (better than 0.5% of full scale) and multiple test ranges. The instrument is designed with 16 independent test modes and bidirectional test mode of stretching and compression, which can meet various test requirements.

Features

Professional

• Better than 0.5% of full scale effectively ensures accurate test results
• 16 independent test modes are available, including compression force, tensile strength, and peel strength of medical appliances and foams
• Professional pressure sensor monitors the internal pressure change during the test of force properties
• The system supports bidirectional test mode of stretching and compression, and 6 test speed can be freely selected based on user requirements
• Intelligent designs of over-travel protection, overload protection, and automatic position reset for safe test operation

Intelligent

This instrument utilizes Labthink's latest embedded computer control system and operating software, with user-friendly operating interface and intelligent data management. It also supports Lystem^TM Lab Data Sharing System, which ensures uniform management of test results and test reports.

• Embedded computer control system provides safer and more reliable data management as well as test operation
• The system can be easily operated by a standard monitor, a mouse and a keyboard; without requiring a PC
• The system is equipped with four USB ports and dual Internet ports for convenient input, output and data transfer
• Status monitoring and intelligent reminding of sensor calibration ensure instrument in the best working condition
• Historical data back up and management functions for diversified data analysis
• The system uses the high performance processor core and large storage space, which can conduct data comparison and analysis for 50 parallel tests at the same time
• Multi-level account control for better data management and protection
• Embedded help document for user viewing at any time
• Supports Lystem^TM Lab Data Sharing System for uniform and systematic data management

Principle

The pre-conditioned specimen is mounted between two grips, which move in relative direction during the test. The changes of force and displacement are separately recorded by the load cell fixed on the driven up and embedded displacement transducer. The relative parameters of force properties can be obtained by further calculation.

Standards

This test instrument conforms to the following standards:
ISO 37, GB 8808, GB/T 1040.1-2006, GB/T 1040.2-2006, GB/T 1040.3-2006, GB/T 1040.4-2006, GB/T 1040.5-2008, GB/T 4850-2002, GB/T 12914-2008, GB/T 17200, GB/T 16578.1-2008, GB/T 7122, GB/T 2790, GB/T 2791, GB/T 2792, GB14232.1-2004, GB15811-2001, GB/T1962.1-2001, GB2637-1995, GB15810-2001, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, QB/T 2358, QB/T 1130, JIS P8113, YY0613-2007, YBB00042002, YBB00112004

Applications

This instrument is equipped with more than 100 grips for tests of more than 1000 materials. And customization is also available for special material tests. Examples of instrument applications:

Technical Specifications

Configurations

Standard Configurations

Instrument, Professional Software, Standard Monitor, Mouse, Keyboard and Universal Grips

Optional Parts

Load Cell, Standard Pressure Roller, Test Plate, Sample Cutter, Floating Roller, Customized Grips, Lystem Lab Data Sharing System, Printer(compatible with PCL3) and Other Test Accessories, e.g. Penetration Test of Rubber Stoppers in Antibiotic Bottles and Hypodermic Needles, Fracture Strength Test of Ampoule Bottles, Leak Test of Plastic Packages under External Pressure, Connection Force Test between Hypodermic Needle and Needle Hub, Connection Force Test between Hypodermic Needle and Needle Cap, Sliding Resistance Test of Pistons, Leak Test of Plastic Packages and Low Speed Unwrapping Device
